5 ply 3 in 1 Automatic Flute Laminator Machine
2 Servo MotorsBelt Drive6000pcs/hourTECHNICAL SPECIFICATIONS:MODELBMC-1300FA5BMC-1450FA5BMC-1600FA5Max. Paper size (W×L)1300×1200mm1450×1200mm1600×1200mmMin. Paper size (W×L)550×550mmFace paper thickness140–600 g/m² (standard paper board)Bottom paperA, B, C,...
Status:
In stock
| 2 Servo Motors |
| Belt Drive |
| 6000pcs/hour |
TECHNICAL SPECIFICATIONS:
| MODEL | BMC-1300FA5 | BMC-1450FA5 | BMC-1600FA5 |
| Max. Paper size (W×L) | 1300×1200mm | 1450×1200mm | 1600×1200mm |
| Min. Paper size (W×L) | 550×550mm | ||
| Face paper thickness | 140–600 g/m² (standard paper board) | ||
| Bottom paper | A, B, C, E, F ≤ 10mm | ||
| Precision | ±1.5mm | ||
| Speed | 4000–6000pcs/h | ||
| Height of face paper pile | 1600mm | ||
| Face paper table capacity | 1500kg | ||
| Height of bottom paper pile | 400mm | ||
| Total Power | 20 kW | 22 kW | 22 kW |
| Dimension (L×W×H) | 15×2.2×2.5 m | 15×2.4×2.5 m | 15×2.5×2.5 m |
| Machine Weight | 5000kg | 5500kg | 6000kg |
