◆ It can nail single nail, double nail, and strengthen nail in one time, making be suitable for different kinds of customer requirements of nails.
◆ It can be changed in size quickly in one minute, can be operated easily, and does not require experience.
◆ The cardboard feeding section can automatically count, send the bundle into the bundle.
◆ It is a man–machine interface control for convenient operation.
◆ Back–automatic counting. The finished products can be sent to the end of the conveyor by setting the number(1–99).
◆Semi–finished products, nailing to the finished products, displayed only need two operators. This can operate simply and reduce wages.
◆ Adopt 4 servo motors, brand YASKAWA.
◆ Feeding unit auto counter.
◆ The computer adjusts nail distance.
◆ Suit for 3–5ply standard carton box.
◆ Nail distance: 30–120mm.
◆ Speed: 500 nails/min.
TECHNICAL SPECIFICATIONS:
| Model | NDSA-3200DSM |
| Max (A + B) × 2 | 3200 mm |
| Min (A + B) × 2 | 1100 mm |
| Max (mm) A | 1400 mm |
| Min (mm) A | 350 mm |
| Min B | 200 mm |
| Min (C + D + C) | 300 mm |
| Total power | 6 kW |
| Nail distance | 30 – 120 mm |
| Machine speed | 500 – 600 nails/min |
| Wire model | 17 – 18 |
| Nail number | 2 – 99 |
| Electric System | Machinery System | Technical Specification |
| Servo AC drive | Mitsubishi Japan | Stitching head | Zhuhai | Speed | 500–600 Nails/min |
| Servo Motor | Mitsubishi Japan | Synchronous pulley | Foshan | Precision | 1 mm |
| PLC | OMRON Japan | Head reducer | Xinbao Japan | Start Method | Sensor or foot switch |
| Contactor | Shili Taiwan | Gear reducer | Zhejiang | Stitching Model | Single piece or double pieces |
| Relay | Schneider French | Synchronous belt | Zhejiang Sanwei | Power | 6 kW |
| Touch screen | Siemens German | | | Weight | 3500 kg |
| Magnetic valve | YDK Taiwan | | | | |
